UFO Arrow 4.8kWh Lithium Solar Battery with LCD Touchscreen

Model:48V 100Ah Lithium Battery for domestic and commercial solar energy storage

ExtantPower Arrow 4.8kWh Lithium Solar Battery with LCD Touchscreen

Description

Model: 48V 100Ah Lithium Battery for domestic and commercial solar energy storage
MOQ: Sample acceptable
Payment: T/T, PayPal, L/C
Delivery time: 30 days
Port of shipment: Shenzhen Port
Price: Get Latest Price

Buy Now Watch Video

*Order now for 2 years of ClickShare Extended Warranty!

Product Information Specifications Company Profile Faqs

In Stock, Free Shipping Buy Now

ExtantPower Arrow 4.8kWh Lithium Solar Battery with LCD Touchscreen

The ExtantPower Arrow is a lithium-ion solar battery with an LCD touchscreen that is the first of its kind in the world. It works with a broad variety of inverters from popular brands such as Growatt, SMA, and Victron. This premium solution for energy storage is your top choice for home power backup because of its distinctive design of a user-friendly LCD touchscreen and industry-leading smart monitoring system. It is simple to install, and the LCD screen makes it simple to keep an eye on your energy consumption. It is also incredibly efficient, which means you will get the most out of your solar panels.

48V

Normal Voltage

42v~54.7v

Voltage Window

51.7v~54.7v

Charge Voltage

0.2C 10A

Charge Current

-20~50°C

Discharge Temperature

0-50°C

Working Temperature

Safety Is Not Biased

10-year Design Life

Compatible with All Brands of Inverters

High Capacity

High Density Space Saving

Intelligent BMS System

The First with an LCD Touchscreen

ExtantPower Arrow 4.8kWh Lithium Solar Battery with LCD Touchscreen

Share And Follow

You can store energy from the grid or solar, using it at any time to power your home.

Show Details

Achieve Market Leading Energy Density

Rechargeable energy storage systems like lithium-ion batteries can be used in series or parallel to increase power.

These batteries are frequently used in equipment powered by wind, solar, and other renewable energy sources.

Along with other renewable energy sources, energy input comes from wind and sun sources.

The electrical energy storage systems can then be employed to produce electricity at various periods of the day.

For instance, renewable energy sources like wind and sun don’t always have the stability needed to consistently produce current;

As a result, difficulties will be remedied with wall-mounted battery packs plugged into the home’s electrical grid.

With this battery, you can keep your home powered during a power outage or even sell energy back to the grid!

24 Hour Power Storage, a home energy storage system with smart battery management system that delivers direct-current current power services for all scenarios. It's perfect for home, microgrid or commercial school use.

Safe & reliable performance with Lithium Iron Phosphate (LFP) cell
Scalable from 5 kilowatts to 18 kilowatts, the modular 2.5 kwh investment is flexible.
Pack level energy optimization provides more usable energy.
suitable for both single-phase and three-phase off-grid / hybrid inverters
To keep the system running, the battery module partially separates itself.
Auto detected by APP

Simple installation, according to the storage needs and able to combine different battery packs.

Buy Now In Stock, Free Shipping

What’s In The Box

Accessory Name 1

Accessory Name 2

Accessory Name 3

Accessory Name 4

Specifications

Basic Specification
Model	2.4kWh	4.8kWh	7.2kWh	9.6kWh
Nominal Voltage	48	48	48	48
Nominal Capacity (Ah)	50	100	150	200
Width (mm)	450	485
Height (mm)	370	650
Depth (mm)	200	200	220	250
Net Weight (kg)	31	55	77	92
IP Level	22	22	22	22
Electrical Specification
Output Power (W)	2.4kW	4.8kW
Voltage Window	42~54.7	42~54.7
Charge Voltage	51.7~54.7	51.7~54.7
Max. Charge/ Discharge Current (A)	50A	100A
Recommend Charge Current	0.2C 10A	0.2C 20A	0.2C 30A	0.2C 40A
Charge Mode	CC-CV
Scalability	15 PCS Up to 36Kwh/72Kwh/108Kwh/144Kwh
Others
Communication	Can/ RS485/ RS232/ Dry Contact
Charge Temperature	0-50°C
Discharge Temperature	-20~50°C
Temperature & Period Storage	12 Months @-10~35°C
	3Months @-10~45°C
	7 day @-20~65°C
Design Life	10+ Years
Cycle Life	More than 6000 Cyclese @25℃ 0.2C 80%DOD
Certification	IEC62619/TUV/UN38.3/ROHS

Company Profile

ExtantPower is an established business with years of experience in the development, manufacture, and marketing of environmentally friendly lithium ion batteries. For specialized and industrial uses, we also manufacture lead-acid, nickel metal hydride, and lithium polymer batteries. We offer an excellent solution for many clients’ needs with our broad selection of wall-mounted battery packs for industrial or household use.

FAQs

1.What is the difference between the 4.8kWh Lithium Battery and the 6.8kWh Lithium Battery?

The 4.8kWh and 6.8kWh lithium batteries have different storage capacities and will provide different durations of power, but they are both excellent choices for off-grid energy storage.

2.Why should I consider purchasing a lithium solar battery?

There are many reasons to consider purchasing lithium solar batteries. They are more durable and have a longer lifespan than traditional lead-acid batteries, and they are also more efficient. Lithium batteries can also be discharged to a lower voltage without damage, making them ideal for solar applications.

3. How to connect a battery in Series?

Batteries are connected in series by connecting the positive terminal of one battery to the negative terminal of the other battery. Batteries are often connected in series to increase the voltage. When batteries are connected in series, the voltage of each battery is added together.

4. How long will my battery last?

A battery's lifespan can vary greatly depending on how it is used, how it is maintained and charged, temperature, and other factors.

5.How can I buy your goods?

Please email your inquiry to our official e-mail (mike@extantpower.com) or use the form below.

6. How long is the lead time?

In general, lead time is the amount of time that passes between the initial purchase order being placed and the product or service being delivered. Our products are created to order, with a sample lead time of 15-35 days and a mass production lead time of 35-45 days.

7. How can I get a sample from you?

After payment, we can send the products to you by express, such as, FedEx, DHL, UPS and so on.

8. How about the Quality Control?

All of our products are manufactured in compliance with national requirements, and we have ISO 9001 certification. Our QC department will perform 3-5 quality checks prior to delivery.

9. How to install the goods?

For a small additional fee, we can send installation drawings or video; or our engineers can do the installation for you.

10. How about the after-sales service?

We will deliver free replacement components or replace them within the first 30 days of purchase.

11. Can you provide R&D service?

Without a doubt. Let our specialists reduce development risks and deliver a high-quality product to market faster when you need a dependable partner to build your custom product.
